| Weight Parameter | Complete Vehicle Kerb Mass（kg） | 6600 | |
| Maximum authorized total mass （kg） | 18000 | ||
| Maximum authorized towed total mass(kg) | 3,200,035,200 | ||
| Dimension Parameter | External Dimensions(mm) | Length | 5950 |
| Width | 2490 | ||
| Height | 307,037,003,870 | ||
| wheelbase(mm) | 3600 | ||
| Minimum Ground Clearance(mm) | 294 | ||
| Performance Parameter | Maximum Speed(km/h) | 93 | |
| Economical Speed(km/h) | 75 | ||
| Maximum Gradeability(%) | 30 | ||
| Turning diameter(m) | 7.03 | ||
| Recommended Configuration | Engine | Engine Type |
WD615.92,WD615.93,WD615.93E,WD615.92E, WD615.92C,WD615.93C,WD615.97C,WD615.97E |
| Rated power(kW)/Rev(r/min) | 196,213,213,196,198,000,000,000 | ||
| Maximum Torque(N*m)/Rev(r/min) | 1160/1300-1600,1100/1300-1600,1100/1100～1600,1190/1200～1500,1290/1200～1500,1160/1100～1600 | ||
| Transmission | HW13710L | ||
| Clutch(mm) | 430 | ||
| Rear Axle | Type | HW1249 | |
| Speed Ratio | 3.91 | ||
| Fuel Tank(L) | 400 | ||
| Chassis Cross-section(mm) | 300 | ||
| Suspension(Front,Back) | 12/9+6,4/9+6,4/5 | ||
| Tyre | 11.00-20 18PR,11.00R20 18PR,12.00-20 20PR,12.00R20 20PR,295/80R22.5 18PR | ||
