No.
|
Part number
|
Quantity
|
Designation
|
Designation
|
Name
|
Note
|
| 1 | AZ1664440011 | 1 | Rear suspension bracket (left) | 长驾驶室后悬左下支架 | ||
| 2 | AZ1664440013 | 1 | Plate | 垫板 | ||
| 3 | Q151B1470 | 4 | Screw | 六角头螺栓 | ||
| 4 | 190003888458 | 4 | Nut | 自锁螺母 | ||
| 5 | AZ1664440012 | 1 | Rear suspensions bracket (right) | 长驾驶室后悬右下支架（与左件对称） | ||
| 6 | AZ1664440013 | 1 | Plate | 垫板 | ||
| 7 | Q151B1470 | 4 | Screw | 六角头螺栓 | ||
| 8 | 190003888458 | 4 | Nut | 自锁螺母 | ||
| 9 | AZ1664440021 | 2 | Rear susupension transitional bracket | 驾驶室后悬过渡支架 | ||
| 10 | Q18416110 | 6 | Screw | 六角法兰螺栓 | ||
| 11 | Q33016 | 6 | Nut | 全金属六角法兰面自锁螺母 | ||
| 12 | WG1664440068 | 2 | Rear susupension assembly (air spring) | 驾驶室后减振器总成（空气弹簧） | ||
| 13 | Q1841490 | 2 | Screw | 六角法兰面螺栓 | ||
| 14 | Q33014 | 2 | Nut | 全金属六角法兰面自锁螺母 | ||
| 15 | AZ1664440091 | 2 | Spacing loop | 隔环 | ||
| 16 | WG1664440101 | 2 | Hydraulic pressure lock assembly | 液压锁总成 | ||
| 17 | Q1841480 | 2 | Screw | 六角法兰面螺栓 | ||
| 18 | Q33014 | 2 | Nut | 全金属六角法兰面自锁螺母 | ||
| 19 | WG1642440021 | 2 | Transverse susupension assembly | 横向稳定减振器总成 | ||
| 20 | AZ1664440031 | 2 | Bush | 衬套 | ||
| 21 | Q40214 | 2 | Washer | 大垫圈 | ||
| 22 | Q18414140 | 2 | Screw | 六角法兰面螺栓 | ||
| 23 | Q33014 | 2 | Nut | 全金属六角法兰面自锁螺母 | ||
| 24 | AZ1664430061 | 2 | Bush | 衬套 | ||
| 25 | Q18414100 | 2 | Screw | 六角法兰面螺栓 | ||
| 26 | Q33014 | 2 | Nut | 全金属六角法兰面自锁螺母 | ||
| 27 | WG1664440050 | 1 | Bracket assembly (left) | 左上支架总成 | ||
| 28 | WG1664440051 | 1 | Bracket assembly (right) | 右上支架总成（与左件对称） | ||
| 29 | Q1840825 | 12 | Screw | 六角法兰面螺拴 | ||
| 30 | WG1642430081 | 2 | Limit block assembly | 限位块总成 | ||
| 31 | WG1642430082 | 2 | Washer | 限位块垫圈 | ||
| 32 | Q40210 | 2 | Washer | 大垫圈 | ||
| 33 | Q40310 | 2 | Washer | 弹簧垫圈 | ||
| 34 | Q340B10 | 2 | Nut | 六角螺母 | ||
| 35 | WG1642440052 | 2 | Lockup signal switch | 驾驶室锁止信号开关 | ||
| 36 | Q150B0630 | 4 | Screw | 六角头螺栓 | ||
| 37 | 199014280016 | 1 | Bush | 衬套 | ||
| 38 | 190003559561 | 1 | Bush | 卡套 | ||
| 39 | 190003559516 | 1 | Nut | 管接头用螺母 | ||
| 40 | WG1642440070 | 1 | Tie in | 三通接头体 | ||
| 41 | 190003559561 | 1 | Bush | 卡套 | ||
| 42 | 190003559516 | 1 | Nut | 管接头用螺母 | ||
| 43 | WG1642440071 | 1 | Tube | 双弯头软管 | ||
| 44 | 190003171356 | 5 | Strain-belt | 塑料紧固带 | ||
| 45 | AZ1664440071 | 1 | Cortrol valve bracket | 高度阀连接支架 | ||
| 46 | Q150B0825 | 4 | Screw | 六角头螺栓 | ||
| 47 | Q40208 | 4 | Washer | 大垫圈 | ||
| 48 | Q40308 | 4 | Washer | 弹簧垫圈 | ||
| 49 | Q340B08 | 4 | Nut | 1型六角螺母 | ||
| 50 | WG1642440051 | 2 | Cortrol valve | 高度控制阀总成 | ||
| 51 | Q150B0855 | 4 | Screw | 六角头螺栓 | ||
| 52 | Q40008 | 4 | Washer | 小垫圈 | ||
| 53 | Q40308 | 4 | Washer | 弹簧垫圈 | ||
| 54 | Q340B08 | 4 | Nut | 1型六角螺母 | ||
| 55 | WG1642440060 | 2 | Push bar | 推杆总成II | ||
| 56 | Q5100614 | 2 | Pin | 销轴 | ||
| 57 | Q5002012 | 2 | Pin opening | 开口销 | ||
| 58 | AZ1642430036 | 4 | Hemispherical washer | 半球垫片 | ||
| 59 | Q340B06 | 8 | Nut | 1型六角螺母 | ||
| 60 | WG1642440055 | 1 | Push-bar bracket (left) | 左推杆支架 | ||
| 61 | WG1642440056 | 1 | Push-bar bracket (right) | 右推杆支架（与左件对称） | ||
| 62 | Q150B0610 | 4 | Screw | 六角头螺拴 | ||
| 63 | Q40306 | 4 | Washer | 弹簧垫圈 | ||
| 64 | 190003179782 | Tube | 聚酰胺管 | |||
| 65 | WG9000361316 | 1 | T-tie in | T型三通接头体3-NW4 |
