No.
|
Part number
|
Quantity
|
Designation
|
Designation
|
Name
|
Note
|
| 1 | AZ1664230007 | 1 | lower,front-cover left for high floor | 高地板低位左前翼子板 | ||
| 2 | AZ1664230006 | 1 | lower,front-cover right for high floor | 高地板低位右前翼子板（与左件对称） | ||
| 3 | AZ1664230009 | 1 | long,rear-cover left for high floor | 高地板左翼子板后段(长) | ||
| 4 | AZ1664230008 | 1 | long,rear-cover right for high floor | 高地板右翼子板后段（长）（与左件对称） | ||
| 5 | AZ1664230011 | 1 | left-cover panel | 左翼子板装饰板 | ||
| 6 | AZ1664230012 | 1 | lright-cover panel | 右翼子板装饰板（与左件对称） | ||
| 7 | AZ1664230057 | 16 | reed nut | 簧片螺母 | ||
| 8 | Q150B0820 | 14 | hexagon screw | 六角头螺栓 | ||
| 9 | Q40108 | 14 | washer | 平垫圈 | ||
| 10 | Q2204816 | 4 | screw | 十字槽盘头自攻螺钉和平垫圈组合件 | ||
| 11 | AZ1664233025 | 1 | middle-breaket left for high-floor | 高地板翼子板左中支架总成 | ||
| 12 | AZ1664233155 | 1 | middle-breaket right for high-floor | 高地板翼子板右中支架总成 | ||
| 13 | Q150B1030 | 10 | hexagon screw | 六角头螺栓 | ||
| 14 | Q40110 | 10 | washer | 平垫圈 | ||
| 15 | AZ1664233030 | 1 | front-breaket left for high-floor | 高地板翼子板左前支架总成 | ||
| 16 | AZ1664233032 | 1 | front-breaket right for high-floor | 高地板翼子板右前支架总成（与左件对称） | ||
| 17 | Q150B0820 | 6 | hexagon screw | 六角头螺栓 | ||
| 18 | Q40108 | 6 | washer | 平垫圈 | ||
| 19 | AZ1664233035 | 1 | rear-breaket left for high-floor | 高地板翼子板左后支架总成 | ||
| 20 | AZ1664233036 | 1 | rear-breaket right for high-floor | 高地板翼子板右后支架总成（与左件对称） | ||
| 21 | Q150B0820 | 4 | hexagon screw | 六角头螺栓 | ||
| 22 | Q40108 | 4 | washer | 平垫圈 | ||
| 23 | AZ1664230061 | lower，U-member left | 高地板低位踏板左托架总成 | |||
| 24 | AZ1664230062 | lower，U-member right | 高地板低位踏板右托架总成（与左件对称） | |||
| 25 | Q150B0820 | 14 | hexagon screw | 六角头螺栓 | ||
| 26 | Q40108 | 14 | washer | 平垫圈 | ||
| 27 | AZ1664230140 | 1 | syringe breaket left | 高地板洗涤器左支架总成 | ||
| 28 | Q150B0820 | 5 | hexagon screw | 六角头螺栓 | ||
| 29 | Q40108 | 5 | washer | 平垫圈 | ||
| 30 | WG1664230081 | 1 | Lower plate left for high-floor | 高地板低位左防滑板 | ||
| 31 | WG1664230082 | 1 | Lower plate right for high-floor | 高地板低位右防滑板（与左件对称） | ||
| 32 | Q2540820 | 8 | screw | 十字槽沉头螺钉 | ||
| 33 | WG1664230051 | 2 | Cover | 堵盖 | ||
| 34 | AZ1664230133 | 1 | left breaket | 翼子板后段左支架 | ||
| 35 | AZ1664230134 | 1 | right breaket | 翼子板后段右支架（与左件对称） | ||
| 36 | AZ1664233225 | 1 | left breaket | 左固定支架 | ||
| 37 | AZ1664233226 | 1 | right breaket | 右固定支架（与左件对称） |
