NO.
|
Part number
|
Qty
|
Name
|
Note
|
| 824 # 1 | WG9719820001 | Manual hydraulic pump | ||
| 824 # 1 | WG9719826001 | Manual hydraulic pump | ||
| 824 # 2 | Q150B1020 | 20.60 partying | ||
| 824 # 3 | Q40310 | Spring pads | ||
| 824? 4 | WG9719820002 | Loading cab tank | ||
| 824 # 5 | WG9719821005 | Knee - high pressure hose (2600) | ||
| 824 # 5 | WG9719820005 | Knee - high pressure hose (2600) | ||
| 824 # 6 | WG9719821006 | Knee - high pressure hose (600) | ||
| 824 # 6 | WG9719820006 | Knee - high pressure hose (1060) | ||
| 824 "7 | WG9719820007 | Knee - High-pressure hose (3150) | ||
| 824? 8 | WG1642440075 | - Elbow Hose | ||
| 824 # 9 | 190003559482 | Maps Packages joints | ||
| 824 ￡ 10 | AZ9719820008 | Cab overturned tank support shaft I | ||
| 824? 11 | AZ9719820009 | Bush | ||
| 824 "12162 | Q40216 | Large washers | ||
| 824? 13 | AZ9719820012 | Bush | ||
| 824 "14 | 190003888459 | With little nut | ||
| 824? 15 | Q700B06 | Straight - through mouth slip fat | ||
| 824? 16 | AZ9719820010 | Cab overturned tank with the axis II | ||
| 824? 17 | EG9719820011 | Large gasket | ||
| 824? 18 | Q40124 | - Washing | ||
| 824? 19 | WG1642440072 | - Elbow Hose | ||
| 824? 20 | Q33424 | With little nut | ||
| 824? 21 | WG9719820013 | Washers | ||
| 824? 22 | AZ9719820021 | Hold | ||
| 826 "23 | Q5101428 | Pin (H11) | ||
| 826? 24 | Q40114 | - Washing | ||
| 826? 26 | Q41814 | Oscillogram of a flexible sealant | ||
| 826? 27 | AZ9719820022 | On the banks of | ||
| 826? 28 | 190003903452 | Pin |
