NO. |
Part number |
Note |
Name |
1 |
JS130T-1701108 |
|
Synchronizer |
1 |
16118 |
|
Synchronizer |
2 |
18701 |
|
Washer |
3 |
JS100-1701113 |
|
Washer |
3 |
14749 |
|
Washer |
4 |
JS150-1701113 |
|
Gear overdrive |
4 |
JS100TA-1701131 |
|
Gear 4 assists |
4 |
19242 |
|
Gear 3rd transfer |
4 |
16748 |
|
Gear 3rd transfer |
4 |
T116E-1701132 |
|
Gear overdrive |
4 |
JS100TA-1701131 |
|
Gear 4-th transmission |
4 |
JS100T-1701131 |
|
Gear 3rd transfer |
4 |
JS100T-1701131 |
|
3-speed gear |
4 |
JS130TA-1701131 |
|
Gear 4-th transmission |
4 |
19638 |
|
Gear overdrive |
4 |
JS180T-1701131 |
|
Pinion 3rd peredachii init?? 0 |
5 |
14750 |
|
Circlip |
6 |
JS100T-1701130 |
|
2-nd gear transmission |
6 |
19614 |
|
2-nd gear transmission |
6 |
16750 |
|
2-nd gear transmission |
6 |
JS130T-17001130 |
|
2-nd gear transmission |
6 |
JS180T-1701130 |
|
2-nd gear transmission |
6 |
JS150-1701112 |
|
2-nd gear transmission |
6 |
19622 |
|
2-nd gear transmission |
7 |
016752 |
|
Gear synchronizer 1 transfers |
7 |
JS180T-1701112 |
|
Gear 1 st transfer |
7 |
JS150-1701111 |
|
Gear 1 st transfer |
7 |
19628 |
|
Gear 1 st transfer |
7 |
19246 |
|
Gear 1 st transfer |
7 |
JS100T-1701112 |
|
Gear 1 st transfer |
7 |
16752 |
|
Gear 1 st transfer |
7 |
JS130T-1701112 |
|
Gear 1 st transfer |
7 |
JS100T-1701112 |
|
Gear 1 st transfer |
8 |
16754 |
|
Gear transmission of slow progress |
9 |
JS100-1701111 |
|
Gear reverse |
9 |
16756 |
|
Gear reverse |
9 |
JS180T-1701111 |
|
Gear reverse |
10 |
62504 |
|
Pin |
11 |
17109 |
|
Dowel |
12 |
JS180T-1701105 |
|
Main shaft |
12 |
18729 |
|
Main shaft |
12 |
JS130T-1701105 |
|
Main shaft |
12 |
JS180-1701105 |
|
Main shaft |
