NO.
|
Part number
|
Qty
|
Name
|
Note
|
| 1 | 0630501028 | Circlip shaft | ||
| 2 | 0750116019 | Roller A， D | ||
| 2 | 0570304002 | Roller C， G | ||
| 2 | 0735355014 | Roller B， F | ||
| 4 | 0769144033 | A set of locking ring shaft | ||
| 5 | 0769140115 | Set adjusting washers | ||
| 6 | 1269304196 | Hub synchronized 3-4-th gear A， D | ||
| 6 | 1310302045 | Hub synchronized 3-4-th gear B， F | ||
| 6 | 1268304142 | Sinhronizatsii3 Hub-4-th referral， G | ||
| 7 | 1250304292 | Ring synchronization， G， A， D | ||
| 9 | 1272304076 | Ring synchronization， G， A， D | ||
| 9 | 1268304594 | Ring sync， F | ||
| 10 | 1310304158 | Gear coupling synchronization 3-4-th gear B， F | ||
| 10 | 1268304143 | nism 8 x 4 | ||
| 11 | 1292304041 | Gear coupling synchronization 3-4-th gear A， D | ||
| 12 | 1272304077 | Bracket sync A， D， C， G | ||
| 12 | 1310304195 | Bracket synchronization， F | ||
| 16 | 0732040385 | Outer spring pusher A， D， C， G | ||
| 16 | 1311304021 | Outer spring pusher B， F | ||
| 17 | 0732040386 | Inner spring pusher | ||
| 18 | 1240304278 | Push portion | ||
| 18 | 1311304020 | Push Part D， F | ||
| 25 | 1292304047 | Gear third transmission secondary shaft A， D | ||
| 25 | 2129304005 | Gear third transmission secondary shaft， F | ||
| 25 | 2128304001 | Gear third transmission secondary shaft Z = 34 C， G | ||
| 26 | 0735320499 | Needle bearing pinion third transmission A， B， D， F | ||
| 26 | 0735320314 | Needle bearing pinion third referral， G | ||
| 27 | 1269304197 | Cage A， D | ||
| 27 | 2159304010 | In the cage， F | ||
| 27 | 115304009 | Racer gears 2 nd-referral， G | ||
| 30 | 1292304046 | Gear 2 nd transmission secondary shaft A， D | ||
| 30 | 2128304016 | Gear 2 nd transmission secondary shaft Z = 38 | ||
| 30 | 2159304004 | Gear 2 nd transmission secondary shaft， F | ||
| 31 | 735320418 | Needle Bearing 2-nd gear transmission | ||
| 31 | ê808840 | Needle Bearing 2-nd gear transmission， F | ||
| 31 | 735320465 | Needle Bearing 2-nd gear transfer A， D | ||
| 33 | 1312304027 | Hub Sync 1-2-nd gear B， F | ||
| 33 | 1250304351 | Hub Sync 1-2-nd gear A， D， C， G | ||
| 34 | 115144034 | A set of locking ring shaft | ||
| 37 | 1272304076 | Ring sync A， D， C， F | ||
| 37 | 1297304402 | Ring sync， F | ||
| 38 | 115304045 | Gear coupling synchronization 1-2-nd gear | ||
| 38 | 1292304052 | Gear coupling synchronization 1-2-nd gear A， D | ||
| 38 | 2159304011 | Gear coupling synchronization 1-2-nd gear B， F | ||
| 40 | 1312302057 | Bracket synchronization 1-2-nd gear B， F | ||
| 40 | 1240304375 | Bracket synchronization 1-2-nd gear A， D | ||
| 40 | 1272304077 | Bracket synchronization 1-2-nd gear | ||
| 42 | 1311304021 | Outer spring pusher B， F | ||
| 42 | 732040385 | Outer spring pusher A， D， C， G | ||
| 43 | 732040386 | Inner spring pusher | ||
| 44 | 1240304278 | Push of A， D， C， G | ||
| 44 | 1311304020 | Push Part B， F | ||
| 45 | 735320418 | Needle bearing gear transmission 1 st A， D， C， G | ||
| 45 | 735320401 | Needle bearing gear 1-y transmission， F | ||
| 46 | 2128304017 | Gear 1-th transmission secondary shaft C， G | ||
| 46 | 1292304045 | Gear 1-th transmission secondary shaft A， D | ||
| 46 | 2159304003 | Gear 1-th transmission secondary shaft， F | ||
| 60 | 2159304001 | Secondary shaft， F | ||
| 60 | 1292304069 | Secondary shaft A， D | ||
| 60 | 2128304007 | Secondary shaft C， G | ||
| 65 | ê808840 | Needle bearing low gear transmission， F | ||
| 65 | ê909822.5 | Needle bearing gear reduced reverse gear C， G | ||
| 65 | 735320466 | Needle bearing gear reduced reverse gear A， D | ||
| 65a | ê808835 | Needle bearing gear in reverse， F | ||
| 70 | 2159304014 | Gear reduced transmission of the secondary shaft， F | ||
| 70 | 1292304018 | Gear reduced transmission of the secondary shaft A， D | ||
| 75 | 1292304026 | Connecting low gear clutch reverse A， D | ||
| 75 | 2159304015 | Connecting low gear clutch reverse B， F | ||
| 76 | 732040497 | Setting spring coupling | ||
| 77 | 635460010 | Ball | ||
| 78 | 2159304017 | Coupling low reverse B， F | ||
| 78 | 1292304025 | Coupling low reverse A， D | ||
| 78 | 2128304006 | Coupling reverse C， G | ||
| 90 | 2159304016 | Gear reverse the secondary shaft， F | ||
| 90 | 1292304017 | Gear reverse the secondary shaft A， D | ||
| 90 | 2128304005 | Gear reverse the secondary shaft C， G | ||
| 92 | 1292304027 | Ring gear bearing reversing secondary shaft A， D， C， G | ||
| 92 | 2159304009 | Ring gear bearing reversing secondary shaft， F | ||
| 95 | 528304001 | Roller bearings with short rollers C， G | ||
| 95 | 750115081 | Roller bearings with short videos A， D | ||
| 95 | 2159304013 | Tapered roller bearings B， F | ||
| 96 | 115144034 | Elastic retaining ring shaft， F | ||
| 96 | 630503020 | Retainer ring bearing A， D， C， G | ||
| 97 | 1286304022 | Sun gear B， F | ||
| 97 | 1269304055 | Sun gear A， D | ||
| 110 | 1269304070 | Thrust plate end of the secondary shaft A， B， D， F | ||
| 110 | 2128304010 | Thrust plate end of the secondary shaft C-G | ||
| 120 | 630015195 | Bolt hole in the head M10h30 A， B， D， F | ||
| 121 | 666890004 | Pin 1.8MM A， B， D， F | ||
| 125 | 730061842 | Oil pipe of the secondary shaft A， B， D. F | ||
| 125a | 2159304012 | Bushing oil tube B. F |
