NO.
|
Part number
|
Qty
|
Name
|
Note
|
| 304_1 | 2159302008 | Shell SAE1 Clutch # | ||
| 304_1 | 1096302089 | SAE1 # clutch Shell | ||
| 304_2 | Q151B1895TF2 | The first bolt MI - 18 who has made 20.60 * 1.5 * 60 | ||
| 304_3 | 1096302076 | From Isolation | ||
| 304_4 | 302322002 | Hollow Bolt | ||
| 304_5 | 634801152 | Gaskets lap A10 * 13,5 | ||
| 304_6 | 99012210065 | Hose | ||
| 304_7 | 109301075 | GLib joints | ||
| 304_8 | Q700B01 | Straight - through mouth slip fat | ||
| 304_9 | 1156302010 | Separation Plectrum | ||
| 304_9 | 2159302009 | Separation Plectrum | ||
| 304_10 | 1156302011 | Tightening the screws | ||
| 304_11 | 1156302013 | Return Spring | ||
| 304_12 | 1156302014 | Return Spring | ||
| 304_13 | 2159202001 | Fasteners | ||
| 304_13 | 2159302013 | Separation fork shaft | ||
| 304_14 | 1156302006 | - Bond | ||
| 304_15 | 2159302012 | 2528 kg | ||
| 304_15 | 1156302012 | 2528 kg | ||
| 304_16 | 108302062 | Sealing rings | ||
| 304_17 | 2159302052 | Check the Hong Kong apartment | ||
| 304_17 | 108302052 | Check the Hong Kong apartment | ||
| 304_18 | 636015020 | * 12 screws M5 | ||
| 304_19 | 2159302011 | Since the axis of the spring collar | ||
| 304_20 | 116302027 | The axis of the spring collar 1.2 |
