NO. |
Part number |
Note |
Name |
1 |
WG9716470150 |
|
ZF8098 steering mechanism ZF8098 (right wheel) |
1 |
AZ9100470225 |
|
ZF8095 steering mechanism |
1 |
AZ9719470228 |
|
ZF8098 steering mechanism |
2 |
AZ9725470229 |
|
Gidroshlang assembly K ZF8095 |
2 |
AZ9716470050 |
|
Gidroshlang assembly RHD |
2 |
AZ9719470029 |
|
Gidroshlang assembly K ZF8098 |
3 |
T071800 |
|
T071800 Combined gland seal |
4 |
190003962632 |
|
Hollow bolt K ZF8098 |
5 |
252? 3407054 |
|
Seal |
6 |
252? 3407055 |
|
Fastening nut |
7 |
252? 3407056 |
|
Socket-gon |
8 |
190003883242 |
|
Nut for fitting |
9 |
WG9100470078 |
|
Fitting for hoses |
10 |
190003989336 |
|
Hose clamp |
11 |
WG9725470050 |
|
The rubber hose with a fibrous layer |
11 |
AZ9716470060 |
|
The rubber hose with a fibrous layer RHD |
11a |
17017470015 |
|
The protective ring spring |
12 |
Q151B045TF2 |
|
Bolt |
13 |
WG9719470020 |
|
Steering fry K ZF8098 |
13 |
WG9716470020 |
|
Steering fry RHD |
13 |
WG9725470298 |
|
Steering fry K ZF8095 |
15 |
Q150B0630 |
|
Bolt |
16 |
Q340B06 |
|
Nut |
17 |
Q40206 |
|
Washer |
18 |
Q40306 |
|
Spring washer |
19 |
1397350169 |
|
Corner Bracket |
20 |
190003489292 |
|
Bushing |
21 |
Q68225 |
|
Deaf clip |
22 |
Q150B0620 |
|
Bolt |
23 |
Q340B06 |
|
Nut |
29 |
AZ9725470020 |
|
Bracket assembly |
34 |
AZ9100470040 |
|
Bracket hydraulic tank assembly |
35 |
WG9719470033 |
|
Hydraulic Tank |
36 |
WG9619470080 |
|
Hydraulic pumps,hydraulic K ZF8095 |
36 |
WG9719470037 |
|
Hydraulic pumps,hydraulic K ZF8098 |
36 |
WG9631470060 |
|
Hydraulic pumps,hydraulic K WD618 |
42 |
WG9100470107 |
|
High pressure hose |
42 |
WG2032470140 |
|
High pressure hose RHD |
44 |
WG9725470120 |
|
Shaped hose |
