NO. |
Part number |
Note |
Name |
1 |
AZ9719470228 |
|
The steering mechanism ZF8098 |
2 |
WG9118470051 |
|
Steering fry |
3 |
252? 3407054 |
|
Gland seal |
4 |
252? 3407055 |
|
Fastening nut |
5 |
252? 3407056 |
|
Socket-gon |
6 |
WG9100470078 |
|
Clutch Hose |
7 |
190003989336 |
|
Hose clamp |
8 |
190003883242 |
|
Nut for fitting |
9 |
190003962632 |
|
Hollow bolt |
10 |
T071800 |
|
Multiple gland seal |
12 |
WG9719470029 |
|
Gidroshlang assembly |
13 |
Q150B0620 |
|
Bolt |
14 |
Q40306 |
|
Spring washer |
15 |
Q340B06 |
|
Nut |
16 |
139735169 |
|
Corner Bracket |
17 |
138091360181 |
|
Tube-holder |
18 |
161000060211 |
|
code init?? 0Rezinovy shlan |
20 |
Q40206 |
|
Washer |
21 |
WG9100470107 |
|
High pressure hose |
22 |
199100470110 |
|
Connection |
23 |
WG9100470076 |
|
Connection head |
24 |
190003962651 |
|
Hollow bolt |
25 |
190003098031 |
|
Sealing washer |
26 |
WG9725470120 |
|
Shaped hose |
27 |
AZ9100470084 |
|
The protective ring spring |
28 |
190003989301 |
|
Hose Clamps |
29 |
WG9719470037 |
|
Hydraulic pumps, hydraulic |
30 |
Q150B0835 |
|
Bolt |
31 |
Q33208 |
|
Keeper |
32 |
WG9719470033 |
|
Hydraulic Tank |
33 |
AZ9100470040 |
|
Bracket hydraulic tank assembly |
41 |
AZ9731470035 |
|
The support plate assembly |
42 |
WG9018470016 |
|
Lever assembly |
43 |
199018470014 |
|
Disc Bearing |
44 |
WG90410228 |
|
Needle bearing (NK4020A) |
73 |
199018510018 |
|
Bracket assembly |
74 |
AZ9118470024 |
|
Ball socket assembly |
75 |
Q80114 |
|
Nut fitting |
77 |
WG2032470140 |
|
High pressure hose assemblies |
78 |
WG9014470008 |
|
Ram |
79 |
AZ9118470025 |
|
Ball socket assembly |
86 |
WG9114470106 |
|
Absorber |
89 |
199118470033 |
|
Steel corner assembly |
90 |
Q271B14 |
|
Nut slot |
