NO.
|
Part number
|
Qty
|
Name
|
Note
|
| 1 | AZ9719520005 | Front Spring Bracket | ||
| 2 | Q151B1665 | Bolt | ||
| 3 | Q151B1650 | Bolt | ||
| 4 | 19003888459 | Nut | ||
| 5 | AZ9232520010 | Spring Bracket Left | ||
| 5a | AZ9232520011 | Spring Bracket right | ||
| 6 | Q151B1650 | Bolt | ||
| 8 | 190003888459 | Locknuts | ||
| 9 | WG9114510510 | Crossbeam | ||
| 10 | 199100520025 | Plate | ||
| 13 | Q151G1260 | Bolt | ||
| 14 | 190003888457 | Locknuts | ||
| 15 | WG9000520078 | Bush | ||
| 16 | WG9100520034 | Leaf earrings | ||
| 17 | WG9100520065 | Central spring bolt | ||
| 20 | 1680520050 | |||
| 21 | Q151C1270 | Bolt | ||
| 22 | Q151C1275code | Bolt | ||
| 23 | 190003888457 | Locknuts | ||
| 24 | 190003963115 | Elbow grease blower | ||
| 26 | 190003963127 | Elbow grease blower | ||
| 27 | WG80520002 | Strap | ||
| 28 | AZ9100520015 | Ladder mounting springs K / 4 × 2，O，S | ||
| 28 | 199014520259 | Ladder mounting springs K / 6 × 4 | ||
| 29 | 1680520056 | |||
| 30 | 190003888626 | Locknuts | ||
| 31 | WG9323520010 | Baffle | ||
| 32 | 1880520019 | Bolt | ||
| 33 | Q340B10 | Nut | ||
| 34 | Q40310 | Grover | ||
| 38 | WG9100520042 | Front spring right K / 4 × 2，O，S | ||
| 38 | WG9725520072 | The front left spring K / 6 × 4 | ||
| 38 | WG9725520073 | Front spring right K / 6 × 4 | ||
| 38 | WG9100520002 | The front left spring K / 4 × 2，O，S |
