NO.
|
Part number
|
Qty
|
Name
|
Note
|
| 0` | AZ9725520022 | The axis of the balancer assembly with the body (clauses 1-20，55) O，K/6h4 / 8x4 to the bridge HOWO 1697 | ||
| 0` | AZ9725520110 | The axis of the balancer assembly with the body (clauses 1-20，55) to bridge STEYR | ||
| 0` | AZ9725520100 | The axis of the balancer assembly with the body (clauses 1-20，55) S/6x4/8x4 to bridge NOWO 1697 | ||
| 1 | AZ9232520004 | The axis of the balancer assembly | ||
| 3 | Q5211645 | Finger | ||
| 4 | WG9014520227 | Hairpin | ||
| 5 | 190003871353 | Nut | ||
| 6 | 199114520035 | Axle housing | ||
| 6 | 199114520233 | Axle housing | ||
| 7 | 199114520136 | Follower bearing | ||
| 8 | 1614130062 | Seal | ||
| 9 | AZ9114520223 | Seal Shaft | ||
| 10 | AZ9114520222 | Shaped ring | ||
| 11 | 199014520191 | Distance sleeve | ||
| 12 | 199014520192 | 0Ustanovochnaya washer Optional | ||
| 12a | 199014520193 | Mounting washer Optional | ||
| 12b | 199014520194 | Mounting washer Optional | ||
| 12c | 199014520303 | Mounting washer Optional | ||
| 12d | 199014520306 | Mounting washer Optional | ||
| 12e | 99114520059 | Mounting washer Optional | ||
| 12f | AZ9100520008 | Mounting washer Optional | ||
| 13 | 199014520265 | Lock washer | ||
| 14 | Q171B1655TF2 | Bolt with hole in head | ||
| 14a | WG9114520041 | Bolt | ||
| 15 | 190003962021 | Bolt with conical thread | ||
| 16 | Q150B0810 | Bolt | ||
| 17 | Q72308T5F | Sealing washer | ||
| 18 | 199014520311 | Shoe Cover | ||
| 19 | Q150B0820 | Bolt | ||
| 20 | Q40308 | Spring washer | ||
| 22 | AZ9725520055 | Ladder KWG9731520013 HOWO Bridge | ||
| 22 | AZ9725520053 | Ladder to the WG963 to WG9232520028 8520008 | ||
| 22 | 199114520234 | Ladder (heavy-duty spring) KWG9232520232 STEYR Bridge | ||
| 22 | AZ9725520037 | Ladder to WG9232520008 KWG972550010 | ||
| 23 | 1880340022 | Washer | ||
| 24 | 190003888749 | Self-locking nut low | ||
| 25 | AZ9638520005 | Seat springs | ||
| 26 | 19900052006 | Guide finger | ||
| 27 | AZ9725520001 | Bracket left front STEYR Bridge | ||
| 27a | AZ9725520002 | Bracket right front STEYR Bridge | ||
| 27b | AZ9725520003 | Bracket left rear STEYR Bridge | ||
| 27c | AZ9725520004 | Bracket right rear STEYR Bridge | ||
| 28 | Q151B22230 | Bolt | ||
| 30 | DZ9114520175 | Lower exhaust thrust assembly with Bushes HOWO Bridge | ||
| 30 | 199114520038 | Lower exhaust thrust assembly with Bushes STEYR Bridge 12.00R24 | ||
| 30 | DZ9114520175 | Lower exhaust thrust assembly with Bushes HOWO Bridge | ||
| 30 | WG9114521174 | Lower exhaust thrust assembly with Bushes STEYR Bridge | ||
| 31 | Q151B2090 | Bolt | ||
| 32 | 190003803974 | Nut | ||
| 33 | WG9114521175 | The upper exhaust thrust assembly with Bushes STEYR Bridge | ||
| 33 | 199114520169 | The upper exhaust thrust assembly with donuts 12.00R24 STEYR Bridge | ||
| 33 | DZ9114520174 | The upper exhaust thrust assembly with Bushes STEYR Bridge | ||
| 33a | AZ9114521175-80 | Bushes d = 80 L = 55 | ||
| 33b | AZ9114521175-85 | Bushes reactive rod (? 85 x 77 mm) | ||
| 37 | AZ9114520091 | The buffer arm assembly | ||
| 51 | AZ9232520003 | Bracket Buffer | ||
| 51 | AZ9114520098 | Bracket Buffer | ||
| 59 | WG232520232 | Rear leaf-spring assembly to 12.00R24 STEYR Bridge | ||
| 59 | WG9725520010 | Spring plate of suspension assemblies O/S/6X4 HOWO Bridge | ||
| 59 | WG0638520008 | Rear leaf-spring assembly K/6h4，STEYR 8x4 Bridge | ||
| 59 | WG9232520028 | Rear leaf-spring assembly K/6h4，STEYR 8x4 Bridge | ||
| 59 | WG9232520008 | Spring plate of suspension assemblies S/O/6x4 STEYR Bridge | ||
| 59 | WG9731520013 | Rear leaf-spring assembly K/6h4，8x4 HOWO Bridge | ||
| 61 | AZ9725520016 | The left front bracket reactive Rod HOWO Bridge | ||
| 61 | 199014520292 | Left arm STEYR Bridge | ||
| 61a | 199014520293 | Right bracket STEYR Bridge | ||
| 61a | AZ9725520017 | The front right bracket reactive rod HOWO Bridge | ||
| 61b | AZ9725520018 | Left rear bracket reactive rod HOWO Bridge | ||
| 61c | AZ9725520019 | The right rear bracket reactive rod HOWO Bridge | ||
| 80 | AZ9725520058 | Shoe |
