NO. |
Part number |
Note |
Name |
1 |
1-21-225-038 |
|
Drive shaft |
2 |
190003961903 |
|
|
3 |
190003078775 |
|
Omentum |
4 |
199114250184 |
|
The flange of the secondary shaft |
4 |
199114250184 |
|
Flange |
4 |
1-21-225-037 |
|
Flange |
5 |
1-99-907-052 |
|
Washer |
6 |
190003326236 |
|
Roller bearing |
7 |
1-99-907-055 |
|
Washer |
9 |
190003802639 |
|
|
11 |
199014250102 |
|
Gear |
12 |
199014250064 |
|
|
13 |
199114250082 |
|
Pinion shaft |
14 |
1880250047 |
|
Washer |
15 |
190003326534 |
|
Bearing 32311GB/T297-94 |
16 |
199114250153 |
|
Korektirovochnaya washers (.154 thick) |
16 |
1188320021 |
|
Korektirovochnaya washers (0.1 thick) |
16 |
1188320022 |
|
Korektirovochnaya washers (0.2 thick) |
16 |
1188320023 |
|
Korektirovochnaya washers (0.4 thick) |
17 |
Q218B0616 |
|
Bolt |
18 |
1-99-936-002 |
|
|
19 |
199012250101 |
|
Toothing |
20 |
199012250100 |
|
Toothing |
21 |
190003330105 |
|
Bearing |
22 |
190003330052 |
|
Bearing |
23 |
1-99-936-001 |
|
|
24 |
199114250098 |
|
Countershaft |
25 |
199014250055 |
|
Bearing |
26 |
190003326053 |
|
Bearing |
27 |
199114250216 |
|
|
